5" Fascia IronMan Gutter Machine

4.5 Fascia.png

Description

The IronMan 5" Fascia gutter machine creates seamless, fascia style gutters. Fascia gutters are generally used on homes where fascia boards have not been installed over the rafter tails.  The smooth face of the fascia gutters act as the function of the fascia boards, hiding the edge of the rafter tails from view. These gutters are commonly found in the western part of the United States.

Product Specifications

Gutter Size
5 Inch
Profile
Fascia

Product Details

Download Specification Sheet

Polyurethane Drive Train: - Eliminates the need to load coil prior to transportation (less material waste)
 - Rollform 24 gauge steel
 - Eliminates slippage from cold weather and condensation

.002 Hard Chrome Plated Steel Forming Rollers:
 - Rollforms all recommended materials with minimal or no adjustment
 - Free-floating forming rollers produce less pressure and allow for more product uniformity

Electrical and Control System:
 - Push button entry and exit end controls with safety wiring and jog feature
 - 3/4 HP, 110 volt, single phase motor, 13.6 ampere

Structural Steel Frame:
 - Welded tubular frame

Modular Turnstile Upright System:
 - Transfer bars (ease of coil loading)

Power:
 - 3/4 HP, 110 volt, single phase, 13.6 ampere, totally enclosed fan cooled (T.E.F.C.) motor

Dimensions:
 - Length - 151" (383.54 cm)
 - Height - 48" (122.0 cm)
 - Width - 24" (61.0 cm)

Weight:
 - Approximately 1,375 lbs. (623.68 kg)

Drive:
 - Powered polyurethane drive rollers via chains and sprockets

Shear:
 - Front pull guillotine

Speed:
 - Approximately 35 feet per minute

Controls:
 - Push button entry and exit end controls with jog feature

Recommended Materials:
 Maximum coil width 15"
       Material                    Maximum Gauge
 - Painted Steel                        26
 - Galvanized Steel                  26
 - Ternecoat Steel                    26
 - Galvalume                            26
 - Aluminum                            .032
 - Copper                   16 oz. - 20 oz. 3/4 hard
